High precision: Accurate I-V curve simulation; the voltage accuracy is ±0.1% F.S.; the current accuracy is ±0.1% F.S.
01
High dynamic: The load rise/fall time is about 2.5ms and the switching time is about 5ms; the voltage change rate is 200V/ms
02
High-speed switching: I-V curves can be switched quickly in 100ms
03
Comprehensive I-V curve simulation: Customized, static and dynamic comprehensive curve simulation, which can simulate sandia, EN50530, CGC/GF004, and other standard curves
04
The maximum capacity of a single unit is 1MW, meeting the test requirements for 1000V and 1500V PV inverters
05
It has the powerful universal programmable function
06
It supports parallel operation of multiple sets of the same model to improve the output capacity and facilitates the capacity upgrade
07
Multiple communication interfaces: RS485/LAN/CAN
08
