·Ambient air temperature – 25~45~24 hours average does not exceed + 35.·Installation site not exceeding 2000m above sea level;·Relative humidity of air does not exceed 50% when the maximum ambient air temperature is +40 °C. lt can have higher relative humidity at lower temperatures. The monthly average minimum temperature of the wettest month does not exceed +25 °C, and the monthly average maximum relative humidity of the month does not exceed 90%, taking into account the condensation of products due to temperature changes.·Rated working system:a)Eight-hour working systemb)Intermittent periodic working system (or intermittent working system)c) Uninterrupted working system·The environmental pollution grade is “pollution grade 3”.·Installation category is “Installation category lll”·The series contactors can be installed by screw or on 35mm (CJX2-09 Z~32 Z) and 75mm (CJX2-40 Z~95 Z) U-type instalation rails.
| Model | Rated working currentle A(AC-3) | Rated control power(kW)(AC-3) | Agreed heating current lth A | ||
| 380V | 660V | 380V | 660V | ||
| CJX2-09Z | 9 | 6.6 | 4 | 5.5 | 25 |
| CJX2-12Z | 12 | 8.9 | 5.5 | 7.5 | 25 |
| CJX2-18Z | 18 | 12 | 7.5 | 10 | 32 |
| CJX2-25Z | 25 | 18 | 11 | 15 | 40 |
| CJX2-32Z | 32 | 21 | 15 | 18.5 | 50 |
| CJX2-40Z | 40 | 34 | 18.5 | 30 | 60 |
| CJX2-50Z | 50 | 39 | 22 | 37 | 80 |
| CJX2-65Z | 65 | 42 | 30 | 37 | 80 |
| CJX2-80Z | 80 | 49 | 37 | 45 | 125 |
| CJX2-95Z | 95 | 49 | 45 | 45 | 125 |
