| Standard | IEC60947-3 |
| PV DC CDFH Fuse Holder Pole | 1P |
| Rated Working Voltage | 1000VDC |
| Rated Current | 30A |
| Breaking Capacity | 20kA |
| Max Power Dissipation | 3W |
| Connection and InstallationWire | 2.5mm2-6.0mm2 |
| Terminal Screws | M3.5 |
| Torque | 0.8~1.2N.m |
| Degree of Protection | IP20 |
| Fuse Size | 10x38mm |
| Operating Temperature Range | -30°C~+70°C |
| Mounting | DIN rail IEC/EN 60715 |
| Pollution Degree | 3 |
| Relative Humidity | +20°C ≤95%, +40°C ≤50% |
| Installation Class | III |
| Weight | 0.07kg Per pole |
