Product parameters?
| Air permeability | 6000ml/min@7kpa |
| Membrane material | ePTFE |
| Membrane properties | Waterproof, dustproof and oil proof |
| Main material | Aluminum alloy/stainless steel/copper |
| Color | Bright silver blowing sand |
| Wrench diameter | 30mm |
| O-ring material | HNBR |
| Nut material | Aluminum alloy |
| Flame retardant grade | UL94-V0 |
| Salt spray resistance： | IEC 68-2-11 |
| Working temperature | -40℃~125℃ |
| IP level | IP65-IP68 |
| Explosion-proof threshold pressure： | 8～13kpa |
| Installation torsion | 0.7±0.1Nm |
The specific parameters are subject to the actual engineering drawings and specifications
