SVG adopts a cascaded multi-level H-bridge power unit configuration, utilizing turn-off capable high-power power electronic devices (such as IGBTs) to form a self-commutated bridge circuit. It is connected in parallel to the power grid through a reactor (or step-up transformer). By appropriately adjusting the amplitude and phase of the AC-side output voltage of the bridge circuit or directly controlling the AC-side current, the system can absorb or generate reactive current that meets grid requirements, achieving dynamic reactive power compensation.
Diagram of Working Principle
Operation Mode
Waveform and Phase Diagram
Explanation
No Load Operation Mode
When Ui = Us, SVG does not provide compensation
Inductive Operation Mode
When Ui < Us, SVG is equivalent to a continuously adjustable inductance
Capacitive Operation Mode
When Ui > Us, SVG is equivalent to a continuously adjustable capacitor
Step-Up Type SVG
Direct Hanging Type SVG
Direct Hanging Delta Type SVG
Types of HV-SVG
Indoor Cabinet Type
Indoor Frame Type
Outdoor Container Type
PCB Coating
FCT-ICT Testing
SMT-AOI Inspection
Power Module Production
Complete Machine Assembly
High-Voltage Testing
Automated Complete Testing
Central Control Room
Full-Load Testing
35kV Direct Hanging Indoor
Tongyu Wind Power
35kV Direct Hanging Outdoor
Cuomei Xizang
10kV Direct Hanging Indoor
Baiyun Airport
10kV Direct Hanging Outdoor
Huaneng Group
10kV Direct Hanging Outdoor
Beijing Automobile
10kV Direct Hanging Indoor
Fujian Stone Factory
6kV Direct Hanging Indoor
Yanjiang LNG Storage
35kV Direct Hanging Outdoor
Vietnam
35kV Direct Hanging Outdoor
Uzbekistan
