OVERALL DIMENSIONS |
||||
| DETECTION DISTANCE 2mm | ||||
F l u s h |
DC 10- 30 VDC AC 90- 250 VAC |
NPN | NO | LMF15-3002NA |
| NC | LMF15-3002NB | |||
| NO+NC | LMF15-3002NC | |||
| PNP | NO | LMF15-3002PA | ||
| NC | LMF15-3002PB | |||
| NO+NC | LMF15-3002PC | |||
two wire system |
NO | LMF15-3002LA | ||
| NC | LMF15-3002LB | |||
| SCR Control- lable silicon |
NO | LMF15-2002A | ||
| NC | LMF15-2002B | |||
| NO+NC | ||||
| Relay output | ||||
| DETECTION DISTANCE 4mm | ||||
F l u s h |
DC 10- 30 VDC AC 90- 250 VAC |
NPN | NO | LMF15-3004NA |
| NC | LMF15-3004NB | |||
| NO+NC | LMF15-3004NC | |||
| PNP | NO | LMF15-3004PA | ||
| NC | LMF15-3004PB | |||
| NO+NC | LMF15-3004PC | |||
two wire system |
NO | LMF15-3004LA | ||
| NC | LMF15-3004LB | |||
| SCR Control- lable silicon |
NO | LMF15-2004A | ||
| NC | LMF15-2004B | |||
| NO+NC | ||||
| Relay output | ||||
Controloutput |
DC | 200mA | ||
| SCR/ Relay | ||||
| Output voltagc dropDC/AC | DC<3V、AC<10V | |||
| Consumption current | DC<15mA、AC<10mA | |||
| Standard detected object | 15X15X1(A3铁iron) | |||
| Repeated precision | 0.02 | |||
| DC/AC | ||||
| Working environment temperature | ||||
| Insulation resistance | ||||
| Shell material | ||||
| Protection grade | ||||
| Altemative model at home and abroad | ST-F-口 | |||
