Product parameters?
| Air permeability | 260-2200ml/min@7kpa |
| Membrane material | e-PTFE |
| Membrane properties | Waterproof, dustproof and oil proof |
| Main material | Aluminum alloy/stainless steel/copper |
Color | Aluminum alloy: black oxide/silver oxide Stainless steel: true color Copper: nickel plated brass or Black brass plating |
| Wrench diameter | 23mm |
| O-ring material | Silicone |
| Nut material | Stainless steel/copper |
| Flame retardant grade | UL94-V0 |
| Salt spray resistance | 48H Level 10 |
| Working temperature | -40℃~125℃ |
| IP level | IP65-IP68 |
| Installation torsion | 0.7±0.1Nm |
The specific parameters are subject to the actual engineering drawings and specifications
