In industries, buildings, and infrastructure, the operation of various systems relies on safe and reliable electricity supply, and even a brief power outage can have serious consequences. For this, you need products and systems that can handle various unexpected accidents to meet safety requirements.As a leading global supplier of LV distribution systems, Siemens provides customers with stable, reliable, safe, and intelligent distribution solutions. Whether it's energy security or energy efficiency management, SIVACON 8PT provides you with excellent safety and reliability.
Product advantages Safe, reliable, and intelligent low-voltage distribution solutions
Product features More horizontal busbar specification selectivity, more optimized busbar structure design, achieving higher cost-effectiveness.1/2 functional unit, achieving higher capacity density.Dedicated secondary connectors for communication.Unique secondary wiring channel ensures high-quality communication for intelligent solutions.The patented technology ensures the safety of on-site equipment and personnel through internal arc fault testing, ensuring the safety and reliability of power supply.
Rated voltage | 400V / 690V |
Rated insulation voltage | 1000VAC/1200VDC |
Short time withstand voltage | 2500V(1min) |
Impulse withstand voltage | 12kV |
Rated current | Up to 7400A |
Internal partition | Types 1 to 4b |
IP level | IP30 – IP54 |
Executive standards | IEC61439-2/GB7251.12-2013 |
Internal arcing fault certification | IEC61641 100kA/0.5s |
Seismic testing | A magnitude 8 earthquake on the Richter scale |
Salt spray test | IEC61439 10.22 |
EMC Testing | GB7251 10.12 |
