PerformanceCharacteristic
CPU Technology control
Intelligent LED display:Grid powe.battery.ACoutput.Fault.Saving.Battery capacity.
Intelligent battery management for maximumbattery life
220V/110V AC 50/60Hz is optional
It can work with the generator
Intelligent fan control mode.The fan workat Temperature ≥30℃.the inverter will protect byitself at temperature ≥100℃
Input/Output voltage | Output Power | Battery Voltage | Energy saving |
Language Version：Chinese/English/French/Russian | Charging voltage setting | Battery Capacity setting | Battery type setting |
CommunicationData
Current | Rated power of load | Input/output voltage | Frequency |
Battery capacity | Temperature | Remote control operation | Record of history data |
TechnicalData Greensky
AC output Load | Green Sky 1000W | Green Sky 1500W | Green Sky 2000W |
Nominal AC voltage Optional 220V/120V | 220V/200-240V 120V/105V-132V | 220V/200-240V 120V/105V-132V | 220V/200-240V 120V/105V-132V |
Nominal AC frequency | 50Hz/60Hz | 50Hz/60Hz | 50Hz/60Hz |
Continuous AC power for 3 hours 25℃ | 1050W | 1500W | 2100W |
Continuous AC power 25℃ | 1000W | 1500W | 2000W |
Nominal AC current/ Max.AC current(peak) | 4.55A/13.63A 1ms 8.34A/24.9A 1ms | 6.85A/20.45A 1ms 12.50A/37.55A 1ms | 9.10A/27.28 1ms 16.67A/50A 1ms |
THD output voltage | ≤3% | ≤3% | ≤3% |
Power Factor | 1.0 | 1.0 | 1.0 |
Battery DC input | |||
Battery voltage/range Optional | 12V/10-16V 24V/20-32V 48V/40-64V | 12V/10-16V 24V/20-32V 48V/40-64V | 12V/10-16V 24V/20-32V 48V/40-64V |
Battery type/Battery Capacity | Lead acid 100-1000Ah | Lead acid 100-1000Ah | Lead acid 100-1000Ah |
Efficiency/Self-consumption | |||
Max.efficiency | >90% | >90% | >90% |
Self-consumption with no load | 12W | 15W | 20W |
Self-consumption with no load /standby/for LCD type only | 5W | 5W | 5W |
Full intellective protection | Over voltage/AC short circuit/overload/battery discharge voltage/battery over voltage/overtemperature/over current/overheat protection/ dc polarity label | ||
Dimenstion(L×W×H) | 490×255×200 | 490×255×200 | 490×255×200 |
Net Weight | 25 | 27 | 29 |
Operating temperature range | -20℃ ~ 45℃ | -20℃ ~ 45℃ | -20℃ ~ 40℃ |
Degree of protection according to IEC60529 | IP20 | IP20 | IP20 |
Noise emission typical | ≤30dB (1M) | ≤30dB (1M) | ≤30dB (1M) |
Permissible value for relative humidity | 0% ~ 95% | 0% ~ 95% | 0% ~ 95% |
Accessories | |||
DC terminal | Anderson connector | Anderson connector | Anderson connector |
AC terminal | Europe terminal | Europe terminal | Europe terminal |
Warranty | 2year | 2year | 2year |
Certificate | CE/ISO9001 | CE/ISO9001 | CE/ISO9001 |
Instruction Manual | yes | yes | yes |
Optional Function | |||
Battery Cable | Optional | Optional | Optional |
Interface USB/RS232 | Optional | Optional | Optional |
SNMP Card | Optional | Optional | Optional |
Software CD | Optional | Optional | Optional |
Internet monitor | Optional | Optional | Optional |
Remoted control | Optional | Optional | Optional |
DC reverse polarity protection | Optional | Optional | Optional |
Automatically restart after cut off | Optional | Optional | Optional |
Split phase 220V/110V+-5%:output | Optional | Optional | Optional |
Alarm at inverter mode/silence | Optional | Optional | Optional |
LCD Display | Optional | Optional | Optional |
