| Item | Parameter |
| Main loop rated voltage | AC 380V |
| Rated Frequency | 50Hz |
| Rated insulation voltage | 660V |
| Main Busway Current Rating | 630A ~ 100A |
| Busway rated short endured current Icw | 15kA |
| Electrical clearance | ≥ 10 mm |
| Creepage distance | ≥ 12.5 mm |
| Protection Class | IP30/IP40 (indoor type) |
| IP55/IP65 (outdoor type) |
